我们在使用kubernetes/docker时最重要的是要对数据做持久化，ceph做为一个开源的分布式存储系统，支持对象存储，块存储rbd，文件系cephfs，同时具备高可靠，易扩展等特性，kubernetes+ceph在很多企业已经落地实施，也是目前最成熟可靠的方案，本篇博客主要为大家讲解基于storageclass动态管理存储的整个生命周期。

1.创建kubernetes对接ceph需要的外部客户端rbd-provisioner

注：假如你的kubernetes集群是由kubeadm初始化时，那么kube-controller-manager本身是没有rbd的命令，所以需要添加一个外部插件

quay.io/external_storage/rbd-provisioner:latest，添加方法如下

cat rbd-provisioner.yaml

kind: ClusterRoleapiVersion: rbac.authorization.k8s.io/v1metadata:  name: rbd-provisionerrules:  - apiGroups: [""]    resources: ["persistentvolumes"]    verbs: ["get", "list", "watch", "create", "delete"]  - apiGroups: [""]    resources: ["persistentvolumeclaims"]    verbs: ["get", "list", "watch", "update"]  - apiGroups: ["storage.k8s.io"]    resources: ["storageclasses"]    verbs: ["get", "list", "watch"]  - apiGroups: [""]    resources: ["events"]    verbs: ["create", "update", "patch"]  - apiGroups: [""]    resources: ["services"]    resourceNames: ["kube-dns","coredns"]    verbs: ["list", "get"]---kind: ClusterRoleBindingapiVersion: rbac.authorization.k8s.io/v1metadata:  name: rbd-provisionersubjects:  - kind: ServiceAccount    name: rbd-provisioner    namespace: defaultroleRef:  kind: ClusterRole  name: rbd-provisioner  apiGroup: rbac.authorization.k8s.io---apiVersion: rbac.authorization.k8s.io/v1kind: Rolemetadata:  name: rbd-provisionerrules:- apiGroups: [""]  resources: ["secrets"]  verbs: ["get"]- apiGroups: [""]  resources: ["endpoints"]  verbs: ["get", "list", "watch", "create", "update", "patch"]---apiVersion: rbac.authorization.k8s.io/v1kind: RoleBindingmetadata:  name: rbd-provisionerroleRef:  apiGroup: rbac.authorization.k8s.io  kind: Role  name: rbd-provisionersubjects:- kind: ServiceAccount  name: rbd-provisioner  namespace: default---apiVersion: extensions/v1beta1kind: Deploymentmetadata:  name: rbd-provisionerspec:  replicas: 1  strategy:    type: Recreate  template:    metadata:      labels:        app: rbd-provisioner    spec:      containers:      - name: rbd-provisioner        image: quay.io/external_storage/rbd-provisioner:latest        env:        - name: PROVISIONER_NAME          value: ceph.com/rbd      serviceAccount: rbd-provisioner---apiVersion: v1kind: ServiceAccountmetadata:  name: rbd-provisione

kubectl apply -f rbd-provisioner.yaml

2.创建ceph-secret这个k8s的secret对象，这个secret对象用于k8s volume插件访问ceph集群用的

（1）在ceph集群的管理节点获取client.admin的keyring值，并用base64编码，在ceph集群的管理节点上操作

ceph auth get-key client.admin | base64

获取的结果如下所示

QVFBczlGOWRCVTkrSXhBQThLa1k4VERQQjhVT29wd0FnZkNDQmc9PQ==

（2）创建secret

cat ceph-secret.yaml

apiVersion: v1kind: Secretmetadata:  name: ceph-secrettype: "ceph.com/rbd"data:  key: QVFBczlGOWRCVTkrSXhBQThLa1k4VERQQjhVT29wd0FnZkNDQmc9PQ==

kubectl apply -f ceph-secret.yaml

3.创建storageclass

（1）在ceph集群的管理节点创建pool池

ceph osd pool create k8stest 256

rbd create rbda -s 1024 -p k8stest

rbd feature disable k8stest/rbda object-map fast-diff deep-flatten

（2）在k8s集群的master节点创建storageclass

cat storageclass.yaml

apiVersion: storage.k8s.io/v1kind: StorageClassmetadata:  name: k8s-rbdprovisioner: ceph.com/rbdparameters:  monitors: 192.168.199.201:6789  adminId: admin  adminSecretName: ceph-secret  pool: k8stest  userId: admin  userSecretName: ceph-secret  fsType: xfs  imageFormat: "2"  imageFeatures: "layering"

注：storageclass参数说明

  monitors: 192.168.199.201:6789     #ceph集群的监控节点，如果monitor是多个，可以写多个monitor地址，用,分割  pool: k8stest  #pool池，需要事先创建，在ceph集群的管理节点，按照上面创建pool的步骤创建即可  userId: admin  #k8s访问ceph集群使用admin管理用户  userSecretName: ceph-secret  #k8s访问ceph需要的密钥，就是我们上面创建的secret  fsType: xfs  #rbd块的文件系统类型，可以是xfs，也可以是ext4  imageFormat: "2"  #默认即可  imageFeatures: "layering"  #默认即可

kubectl apply -f storageclass.yaml

4.statefulset+ceph最佳实践测试

cat stat.yaml

apiVersion: v1kind: Servicemetadata:  name: storage  labels:    app: storagespec:  ports:  - port: 80    name: web  clusterIP: None  selector:    app: storage---apiVersion: apps/v1beta1kind: StatefulSetmetadata:  name: storagespec:  serviceName: "storage"  replicas: 2  template:    metadata:      labels:        app: storage    spec:      containers:      - name: nginx        image: nginx        ports:        - containerPort: 80          name: web        volumeMounts:        - name: www          mountPath: /usr/share/nginx/html  volumeClaimTemplates:  - metadata:      name: www    spec:        accessModes: [ "ReadWriteOnce" ]        volumeMode: Filesystem        storageClassName: k8s-rbd        resources:          requests:            storage: 1Gi

kubectl apply -f state.yaml

上面命令执行之后，会自动生成pvc，pv，然后把pvc和pv绑定

上面的pv是通过storageclass这个存储类动态生成的
