背景

今天我们将深入探讨一个备受关注的话题：如何使用 MySQL元数据库，通过 Docker Compose 快速部署 Apache DolphinScheduler 3.1.9 集群。

大家都知道，DolphinScheduler 官方提供的 Docker Compose 部署方案默认使用的是 PostgreSQL 作为元数据存储。这主要是由于 MySQL 的 GPLv2 协议与 Apache License 2.0 之间存在不兼容性，导致官方无法直接提供基于 MySQL 的版本。然而，在实际生产环境中，很多团队更倾向于使用MySQL作为数据库，因为它在运维、工具支持和社区生态方面具有广泛的优势。

本篇文章将为您揭秘，如何在官方方案的基础上进行巧妙调整，让您的 DolphinScheduler 集群成功跑在 MySQL元数据库上。

下载镜像

docker pull apache/dolphinscheduler-master:3.1.9
docker pull apache/dolphinscheduler-worker:3.1.9
docker pull apache/dolphinscheduler-tools:3.1.9
docker pull apache/dolphinscheduler-api:3.1.9
docker pull apache/dolphinscheduler-alert-server:3.1.9
docker pull bitnami/zookeeper:3.7.1

下载MySQL驱动

wget https://downloads.mysql.com/archives/get/p/3/file/mysql-connector-j-8.0.33.zip
unzip -q mysql-connector-j-8.0.33.zip
cp mysql-connector-j-8.0.33/mysql-connector-j-8.0.33.jar .

准备镜像文件

master、worker、api、alert-server使用的Dockerfile

# 基于DolphinScheduler官方镜像
ARG SERVICE=api
FROM apache/dolphinscheduler-${SERVICE}:3.1.9
# 将MySQL JDBC驱动拷贝到DolphinScheduler的lib目录
# DolphinScheduler通常会从其lib目录加载JDBC驱动
COPY mysql-connector-j-8.0.33.jar /opt/dolphinscheduler/libs/

tools使用的Dockerfile

# 基于DolphinScheduler官方镜像
ARG SERVICE=tools
FROM apache/dolphinscheduler-${SERVICE}:3.1.9
# 将MySQL JDBC驱动拷贝到DolphinScheduler的lib目录
# DolphinScheduler通常会从其lib目录加载JDBC驱动
COPY mysql-connector-j-8.0.33.jar /opt/dolphinscheduler/tools/libs/

编译新镜像

docker build --build-arg SERVICE=master -t apache/dolphinscheduler-master:3.1.9-mysql .
docker build --build-arg SERVICE=worker -t apache/dolphinscheduler-worker:3.1.9-mysql .
docker build --build-arg SERVICE=tools -t apache/dolphinscheduler-tools:3.1.9-mysql .
docker build --build-arg SERVICE=api -t apache/dolphinscheduler-api:3.1.9-mysql .
docker build --build-arg SERVICE=alert-server -t apache/dolphinscheduler-alert-server:3.1.9-mysql .

修改docker-compose.yaml

注释掉postgresql service，增加mysql service

# Licensed to the Apache Software Foundation (ASF) under one
# or more contributor license agreements.  See the NOTICE file
# distributed with this work for additional information
# regarding copyright ownership.  The ASF licenses this file
# to you under the Apache License, Version 2.0 (the
# "License"); you may not use this file except in compliance
# with the License.  You may obtain a copy of the License at
#
#     http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
services:
#dolphinscheduler-postgresql:
#  image: bitnami/postgresql:15.2.0
#  ports:
#    - "5432:5432"
#  profiles: ["all", "schema"]
#  environment:
#    POSTGRESQL_USERNAME: root
#    POSTGRESQL_PASSWORD: root
#    POSTGRESQL_DATABASE: dolphinscheduler
#  volumes:
#    - dolphinscheduler-postgresql:/bitnami/postgresql
#  healthcheck:
#    test: ["CMD", "bash", "-c", "cat < /dev/null > /dev/tcp/127.0.0.1/5432"]
#    interval: 5s
#    timeout: 60s
#    retries: 120
#  networks:
#    - dolphinscheduler
# MySQL 数据库服务 (元数据库)
dolphinscheduler-mysql:
image:
mysql:8.0
container_name:
dolphinscheduler-mysql
profiles:
 [
"all"
,
"schema"
]
environment:
MYSQL_ROOT_PASSWORD:
${MYSQL_ROOT_PASSWORD:-root}
MYSQL_DATABASE:
${MYSQL_DATABASE:-dolphinscheduler}
volumes:
-
dolphinscheduler-mysql:/var/lib/mysql
ports:
-
"3306:3306"
# 映射MySQL端口到宿主机，供其他服务器的Worker访问
healthcheck:
test:
 [
"CMD"
,
"mysqladmin"
,
"ping"
,
"-h"
,
"localhost"
,
"-u"
,
"${MYSQL_USERNAME:-root}"
,
"-p${MYSQL_PASSWORD:-root}"
]
# 健康检查，使用 .env 中的用户名密码
interval:
5s
timeout:
60s
retries:
120
networks:
-
dolphinscheduler
dolphinscheduler-zookeeper:
image:
bitnami/zookeeper:3.7.1
profiles:
 [
"all"
]
environment:
ALLOW_ANONYMOUS_LOGIN:
"yes"
ZOO_4LW_COMMANDS_WHITELIST:
srvr,ruok,wchs,cons
ports:
-
"2181:2181"
volumes:
-
dolphinscheduler-zookeeper:/bitnami/zookeeper
healthcheck:
test:
 [
"CMD"
,
"bash"
,
"-c"
,
"cat < /dev/null > /dev/tcp/127.0.0.1/2181"
]
interval:
5s
timeout:
60s
retries:
120
networks:
-
dolphinscheduler
dolphinscheduler-schema-initializer:
image:
${HUB}/dolphinscheduler-tools:${TAG}
env_file:
.env
profiles:
 [
"schema"
]
command:
 [
tools/bin/upgrade-schema.sh
 ]
depends_on:
dolphinscheduler-mysql:
condition:
service_healthy
volumes:
-
dolphinscheduler-logs:/opt/dolphinscheduler/logs
-
dolphinscheduler-shared-local:/opt/soft
-
/dolphinscheduler:/dolphinscheduler
networks:
-
dolphinscheduler
dolphinscheduler-api:
image:
${HUB}/dolphinscheduler-api:${TAG}
ports:
-
"12345:12345"
-
"25333:25333"
profiles:
 [
"all"
]
env_file:
.env
healthcheck:
test:
 [
"CMD"
,
"curl"
,
"http://localhost:12345/dolphinscheduler/actuator/health"
 ]
interval:
30s
timeout:
5s
retries:
3
depends_on:
dolphinscheduler-zookeeper:
condition:
service_healthy
volumes:
-
dolphinscheduler-logs:/opt/dolphinscheduler/logs
-
dolphinscheduler-shared-local:/opt/soft
-
/dolphinscheduler:/dolphinscheduler
networks:
-
dolphinscheduler
dolphinscheduler-alert:
image:
${HUB}/dolphinscheduler-alert-server:${TAG}
profiles:
 [
"all"
]
env_file:
.env
healthcheck:
test:
 [
"CMD"
,
"curl"
,
"http://localhost:50053/actuator/health"
 ]
interval:
30s
timeout:
5s
retries:
3
depends_on:
dolphinscheduler-zookeeper:
condition:
service_healthy
volumes:
-
dolphinscheduler-logs:/opt/dolphinscheduler/logs
networks:
-
dolphinscheduler
dolphinscheduler-master:
image:
${HUB}/dolphinscheduler-master:${TAG}
profiles:
 [
"all"
]
env_file:
.env
environment:
#增加java参数设置
JAVA_OPTS:
-server
-Duser.timezone=${SPRING_JACKSON_TIME_ZONE}
-Xms8g
-Xmx8g
-Xmn4g
-XX:+PrintGCDetails
-Xloggc:gc.loo
g
-XX:+HeapDumpOnOutOfMemoryError
-XX:HeapDumpPath=dump.hprof
healthcheck:
test:
 [
"CMD"
,
"curl"
,
"http://localhost:5679/actuator/health"
 ]
interval:
30s
timeout:
5s
retries:
3
depends_on:
dolphinscheduler-zookeeper:
condition:
service_healthy
volumes:
-
dolphinscheduler-logs:/opt/dolphinscheduler/logs
-
dolphinscheduler-shared-local:/opt/soft
networks:
-
dolphinscheduler
dolphinscheduler-worker:
image:
${HUB}/dolphinscheduler-worker:${TAG}
profiles:
 [
"all"
]
env_file:
.env
environment:
JAVA_OPTS:
-server
-Duser.timezone=${SPRING_JACKSON_TIME_ZONE}
-Xms8g
-Xmx8g
-Xmn4g
-XX:+PrintGCDetails
-Xloggc:gc.loo
g
-XX:+HeapDumpOnOutOfMemoryError
-XX:HeapDumpPath=dump.hprof
healthcheck:
test:
 [
"CMD"
,
"curl"
,
"http://localhost:1235/actuator/health"
 ]
interval:
30s
timeout:
5s
retries:
3
depends_on:
dolphinscheduler-zookeeper:
condition:
service_healthy
volumes:
-
dolphinscheduler-worker-data:/tmp/dolphinscheduler
-
dolphinscheduler-logs:/opt/dolphinscheduler/logs
-
dolphinscheduler-shared-local:/opt/soft
-
/dolphinscheduler:/dolphinscheduler
networks:
-
dolphinscheduler
networks:
dolphinscheduler:
driver:
bridge
volumes:
#注释掉postgresql volume
#dolphinscheduler-postgresql:
dolphinscheduler-mysql:
dolphinscheduler-zookeeper:
dolphinscheduler-worker-data:
dolphinscheduler-logs:
dolphinscheduler-shared-local:

修改.env

# Docker Hub 镜像前缀和版本标签
HUB=apache
TAG=3.1.9
# MySQL 配置
MYSQL_ROOT_PASSWORD=root # 替换为您希望的 MySQL root 密码
MYSQL_DATABASE=dolphinscheduler # Dolphinscheduler 使用的数据库名称
MYSQL_USERNAME=root # Dolphinscheduler 连接 MySQL 的用户名 (通常就是 root)
MYSQL_PASSWORD=root # Dolphinscheduler 连接 MySQL 的密码 (与 root 密码相同)
# Dolphinscheduler 数据库连接配置 (通过 Docker Compose 传递给 DS 服务)
TZ=Asia/Shanghai
#指定使用MySQL数据库
DATABASE=mysql
SPRING_JACKSON_TIME_ZONE=GMT+8
SPRING_DATASOURCE_URL=jdbc:mysql://dolphinscheduler-mysql:3306/${MYSQL_DATABASE}?useUnicode=true&characterEncoding=UTF-8&useSSL=false&serverTimezone=Asia/Shanghai&allowPublicKeyRetrieval=true
SPRING_DATASOURCE_USERNAME=${MYSQL_USERNAME}
SPRING_DATASOURCE_PASSWORD=${MYSQL_PASSWORD}
REGISTRY_ZOOKEEPER_CONNECT_STRING=dolphinscheduler-zookeeper:2181
MASTER_FETCH_COMMAND_NUM=10

初始化数据库

docker compose --profile schema up -d

启动集群

docker compose --profile all up -d

启动Worker服务

docker compose up -d dolphinscheduler-worker

启动Master服务

docker compose up -d dolphinscheduler-master

启动Alert服务

docker compose up -d olphinscheduler-alert

启动api服务

docker compose up -d dolphinscheduler-api

重启所有服务

docker compose --profile all restart

作者：学通 来源： https://juejin.cn/post/7527944272277667855
