13 Docker容器单机网络架构全攻略：使用自定义桥接的实践与探索 五 使用自定义docker桥接网络 5.1 重新创建新的容器 5.2 重新创建新的容器，并且指定网络 5.3 docker网桥切换

13 Docker容器单机网络架构全攻略：使用自定义桥接的实践与探索

五 使用自定义docker桥接网络

5.1 重新创建新的容器

[superman@docker ~]$ docker run -dit --name superman001 alpine

示例：

[superman@docker ~]
$ docker run
-dit
--name superman001 alpine


a7479884a350b2ba36211d91a087f631640b068a2771ca766b9afda880113791


[superman@docker ~]
$


[superman@docker ~]
$ docker
ps
-a


CONTAINER ID   IMAGE     COMMAND     CREATED              STATUS              PORTS     NAMES


a7479884a350   alpine
"/bin/sh"   About a minute ago   Up About a minute             superman001


[superman@docker ~]
$


[superman@docker ~]
$ docker inspect superman001 |
grep
-i ipaddress



"SecondaryIPAddresses": null,



"IPAddress":
"172.17.0.2",



"IPAddress":
"172.17.0.2",


[superman@docker ~]
$


[superman@docker ~]
$ docker network
ls


NETWORK ID     NAME      DRIVER    SCOPE


1aa209e7f1ec   br1       bridge    local


e3124ecf5bf5   bridge    bridge    local


1fe81a14e4c7   host      host      local


008ae2f75ac2   none      null      local


[superman@docker ~]
$


[superman@docker ~]
$ docker network inspect e3124ecf5bf5


[


    {



"Name":
"bridge",



"Id":
"e3124ecf5bf509eed6bae70009b6eee88edf8a3708e5ad0a680dee8804ea8817",



"Created":
"2024-06-27T19:45:15.436074478+08:00",



"Scope":
"local",



"Driver":
"bridge",



"EnableIPv6":
false,



"IPAM": {



"Driver":
"default",



"Options": null,



"Config": [


                {



"Subnet":
"172.17.0.0/16",



"Gateway":
"172.17.0.1"


                }


            ]


        },



"Internal":
false,



"Attachable":
false,



"Ingress":
false,



"ConfigFrom": {



"Network":
""


        },



"ConfigOnly":
false,



"Containers": {



"a7479884a350b2ba36211d91a087f631640b068a2771ca766b9afda880113791": {



"Name":
"superman001",



"EndpointID":
"e22b8b08c943b3524d8b5efae3603ebcb09f8d450ced89c038039cf2e5202ca4",



"MacAddress":
"02:42:ac:11:00:02",



"IPv4Address":
"172.17.0.2/16",



"IPv6Address":
""


            }


        },



"Options": {



"com.docker.network.bridge.default_bridge":
"true",



"com.docker.network.bridge.enable_icc":
"true",



"com.docker.network.bridge.enable_ip_masquerade":
"true",



"com.docker.network.bridge.host_binding_ipv4":
"0.0.0.0",



"com.docker.network.bridge.name":
"docker0",



"com.docker.network.driver.mtu":
"1500"


        },



"Labels": {}


    }


]


[superman@docker ~]
$

5.2 重新创建新的容器，并且指定网络

[superman@docker ~]$ docker run -dit --name superman002 --network br1 alpine

示例：

[superman@docker ~]
$ docker run
-dit
--name superman002
--network br1 alpine


20280f606803e2cd997e6723fd4b1db1fa86074b9d919995890c97154252d0ab


[superman@docker ~]
$


[superman@docker ~]
$ docker
ps
-a


CONTAINER ID   IMAGE     COMMAND     CREATED         STATUS         PORTS     NAMES


20280f606803   alpine
"/bin/sh"
5 seconds ago   Up
4 seconds             superman002


a7479884a350   alpine
"/bin/sh"
7 minutes ago   Up
7 minutes             superman001


[superman@docker ~]
$


[superman@docker ~]
$ docker inspect superman002 |
grep
-i ipaddress



"SecondaryIPAddresses": null,



"IPAddress":
"",



"IPAddress":
"172.16.1.2",


[superman@docker ~]
$


[superman@docker ~]
$ docker network
ls


NETWORK ID     NAME      DRIVER    SCOPE


1aa209e7f1ec   br1       bridge    local


e3124ecf5bf5   bridge    bridge    local


1fe81a14e4c7   host      host      local


008ae2f75ac2   none      null      local


[superman@docker ~]
$


[superman@docker ~]
$ docker network inspect 1aa209e7f1ec


[


    {



"Name":
"br1",



"Id":
"1aa209e7f1ecfb2a31aff43199ac845b90030480b854dba1a3aa2a32cfda74a1",



"Created":
"2024-06-24T11:22:13.046754701+08:00",



"Scope":
"local",



"Driver":
"bridge",



"EnableIPv6":
false,



"IPAM": {



"Driver":
"default",



"Options": {},



"Config": [


                {



"Subnet":
"172.16.1.0/24",



"Gateway":
"172.16.1.1"


                }


            ]


        },



"Internal":
false,



"Attachable":
false,



"Ingress":
false,



"ConfigFrom": {



"Network":
""


        },



"ConfigOnly":
false,



"Containers": {



"20280f606803e2cd997e6723fd4b1db1fa86074b9d919995890c97154252d0ab": {



"Name":
"superman002",



"EndpointID":
"43ff4cf56a63c5f73045e195702dc9eeeef5de31501559700951146e3060332e",



"MacAddress":
"02:42:ac:10:01:02",



"IPv4Address":
"172.16.1.2/24",



"IPv6Address":
""


            }


        },



"Options": {},



"Labels": {}


    }


]


[superman@docker ~]
$

在不同的linux-bridge | docker network之间，默认网络隔离。

5.3 docker网桥切换

[root@centos7 docker]
# docker network disconnect bridge superman001


[root@centos7 docker]
# docker network connect br1 superman001

示例：

[superman@docker ~]
$ docker network disconnect bridge superman001


[superman@docker ~]
$


[superman@docker ~]
$ docker network connect br1 superman001


[superman@docker ~]
$


[superman@docker ~]
$ docker inspect superman001 |
grep
-i ipaddress



"SecondaryIPAddresses": null,



"IPAddress":
"",



"IPAddress":
"172.16.1.3",


[superman@docker ~]
$


[superman@docker ~]
$ docker network
ls


NETWORK ID     NAME      DRIVER    SCOPE


1aa209e7f1ec   br1       bridge    local


e3124ecf5bf5   bridge    bridge    local


1fe81a14e4c7   host      host      local


008ae2f75ac2   none      null      local


[superman@docker ~]
$


[superman@docker ~]
$ docker network inspect 1aa209e7f1ec


[


    {



"Name":
"br1",



"Id":
"1aa209e7f1ecfb2a31aff43199ac845b90030480b854dba1a3aa2a32cfda74a1",



"Created":
"2024-06-24T11:22:13.046754701+08:00",



"Scope":
"local",



"Driver":
"bridge",



"EnableIPv6":
false,



"IPAM": {



"Driver":
"default",



"Options": {},



"Config": [


                {



"Subnet":
"172.16.1.0/24",



"Gateway":
"172.16.1.1"


                }


            ]


        },



"Internal":
false,



"Attachable":
false,



"Ingress":
false,



"ConfigFrom": {



"Network":
""


        },



"ConfigOnly":
false,



"Containers": {



"20280f606803e2cd997e6723fd4b1db1fa86074b9d919995890c97154252d0ab": {



"Name":
"superman002",



"EndpointID":
"43ff4cf56a63c5f73045e195702dc9eeeef5de31501559700951146e3060332e",



"MacAddress":
"02:42:ac:10:01:02",



"IPv4Address":
"172.16.1.2/24",



"IPv6Address":
""


            },



"a7479884a350b2ba36211d91a087f631640b068a2771ca766b9afda880113791": {



"Name":
"superman001",



"EndpointID":
"b2eb9591ef0ffa3a5e242f0a3f539c980e2b441e55654381bd8317dd8fca05e1",



"MacAddress":
"02:42:ac:10:01:03",



"IPv4Address":
"172.16.1.3/24",



"IPv6Address":
""


            }


        },



"Options": {},



"Labels": {}


    }


]


[superman@docker ~]
$

基于主机名的访问（单独创建新的network可以⽀持docker容器主机名和IP地址解析）。
