192.168.1.181 主库--->备库

192.168.1.183 备库--->主库


192.168.1.181

SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY          MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE


SQL> select switchover_status from v$database;

SWITCHOVER_STATUS
--------------------
TO STANDBY


192.168.1.183
SQL> select database_role,protection_level,protection_mode from v$database;

DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PHYSICAL STANDBY MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE

SQL> select switchover_status from v$database;
SWITCHOVER_STATUS
--------------------
RECOVERY NEEDED

192.168.1.181

SQL> alter database commit to switchover to physical standby with session shutdown;  ---2分钟

192.168.1.183

SQL> alter database commit to switchover to primary;
alter database commit to switchover to primary
*
ERROR at line 1:
ORA-16139: media recovery required

SQL> alter database recover managed standby database disconnect from session;

SQL> alter database commit to switchover to primary;

192.168.1.181
SQL> shutdown immediate
SQL> startup nomount
SQL> alter database mount;
SQL> alter database recover managed standby database disconnect from session;

192.168.1.183
SQL> alter database open;

测试
192.168.1.181

SQL> select dest_name,status from v$archive_dest_status;

DEST_NAME                 STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1        VALID
LOG_ARCHIVE_DEST_2        VALID

SQL> select database_role,protection_level,protection_mode from v$database;

DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PHYSICAL STANDBY MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE

SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_orcl
Oldest online log sequence     0
Next log sequence to archive   0
Current log sequence           38

192.168.1.183

SQL> select  dest_name,status from v$archive_dest_status;

DEST_NAME                 STATUS
------------------------- ---------
LOG_ARCHIVE_DEST_1        VALID
LOG_ARCHIVE_DEST_2        VALID


SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY          MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE

SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_db01
Oldest online log sequence     36
Next log sequence to archive   38
Current log sequence           38

SQL> alter system switch logfile;

192.168.1.181

SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_orcl
Oldest online log sequence     37
Next log sequence to archive   0
Current log sequence           39


192.168.1.181 备库--->主库

192.168.1.183 主库--->备库

192.168.1.183
SQL> alter database commit to switchover to physical standby with session shutdown;

192.168.1.181
SQL> alter database commit to switchover to primary;

192.168.1.183
SQL> alter database recover managed standby database disconnect from session;

192.168.1.181
SQL> alter database open;

测试

192.168.1.181

SQL> select instance_name,status from v$instance;

INSTANCE_NAME    STATUS
---------------- ------------
orcl             OPEN

SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PRIMARY          MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE


SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_orcl
Oldest online log sequence     42
Next log sequence to archive   44
Current log sequence           44

192.168.1.183

SQL> select instance_name,status from v$instance;

INSTANCE_NAME    STATUS
---------------- ------------
db01             MOUNTED

SQL> select database_role,protection_level,protection_mode from v$database;
DATABASE_ROLE    PROTECTION_LEVEL     PROTECTION_MODE
---------------- -------------------- --------------------
PHYSICAL STANDBY MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE


SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_db01
Oldest online log sequence     0
Next log sequence to archive   0
Current log sequence           44


192.168.1.181
SQL> alter system switch logfile;

192.168.1.183
SQL> archive log list
Database log mode              Archive Mode
Automatic archival             Enabled
Archive destination            /home/oracle/arch_db01
Oldest online log sequence     43
Next log sequence to archive   0
Current log sequence           45
