某个支付系统11.2.0.3的rac系统，其中一个节点忽然无法启动
1.尝试关闭集群重新启动集群
[root@rac2 ~]$ crsctl stop crs -f
2.尝试重新启动集群
[root@rac2 ~]$ crsctl start crs
CRS-4123: Oracle High Availability Services has been started.
集群启动成功，无其他报错，此时感觉asm已经起来了
[grid@rac2 ~]$ ps -ef | grep smon
root 8472 1 1 14:14 ? 00:00:01 /u01/app/11.2/product/crs_1/bin/osysmond.bin
grid 9238 1 0 14:15 ? 00:00:00 asm_smon_+ASM2
grid 9500 6212 0 14:16 pts/5 00:00:00 grep smon
这时试图连接ASM查看dg状态，奇怪的事情发生了，asm可以登录，但是查询asmdisk报错
[grid@rac2 ~]$ sqlplus / as sysasm
SQL*Plus: Release 11.2.0.3.0 Production on Wed May 21 15:35:05 2014
Connected to:
Oracle Database 11g Enterprise Edition Release 11.2.0.3.0 - 64bit Production
With the Real Application Clusters and Automatic Storage Management options
SQL> select status from v$asm_disk;
select status from v$asm_disk
*
ERROR at line 1:
ORA-01034: ORACLE not available
Process ID: 14465
Session ID: 2707 Serial number: 3
查看d.bin进程，发现crsd并没有起来
[root@rac01 ~]# ps -ef | grep d.bin
root 4142 1 0 09:27 ? 00:00:05 /u01/app/11.2.0/grid/product/db_1/bin/ohasd.bin reboot
grid 4548 1 0 09:28 ? 00:00:00 /u01/app/11.2.0/grid/product/db_1/bin/mdnsd.bin
grid 4558 1 0 09:28 ? 00:00:01 /u01/app/11.2.0/grid/product/db_1/bin/gpnpd.bin
grid 4568 1 0 09:28 ? 00:00:05 /u01/app/11.2.0/grid/product/db_1/bin/gipcd.bin
root 4590 1 0 09:28 ? 00:00:10 /u01/app/11.2.0/grid/product/db_1/bin/osysmond.bin
再次查看asm进程，还是存在相应的asm实例进程
[grid@rac2 ~]$ ps -ef | grep smon
root 17377 1 2 14:31 ? 00:00:09 /u01/app/11.2/product/crs_1/bin/osysmond.bin
grid 21518 1 0 14:37 ? 00:00:00 asm_smon_+ASM2
grid 21615 18834 0 14:37 pts/5 00:00:00 grep smon
登录asmcmd，也同样抛出异常
[grid@rac2 ~]$ asmcmd
ORA-01034: ORACLE not available
Process ID: 21716
Session ID: 2707 Serial number: 1 (DBD ERROR: OCIStmtExecute/Describe)
ocr无法进行正常check
[root@rac2 bin]# ./ocrcheck
PROT-602: Failed to retrieve data from the cluster registry
PROC-26: Error while accessing the physical storage
ORA-15077: could not locate ASM instance serving a required diskgroup
关闭asm,尝试手动启动asm实例，同样无法启动asm实例
[grid@rac2 ~]$ sqlplus / as sysasm
SQL*Plus: Release 11.2.0.3.0 Production on Wed May 21 14:33:37 2014
Copyright (c) 1982, 2011, Oracle. All rights reserved.
SQL> shutdown abort
ASM instance shutdown
SQL> startup
ORA-27103: internal error
Linux-x86_64 Error: 2: No such file or directory
Additional information: 1
Additional information: 25919497
Additional information: 2
通过+ASM1实例的spfile 创建新的pfile尝试启动+ASM2实例，同样无法启动+ASM2实例
SQL> startup nomount pfile='/tmp/init+asm2.ora';
ORA-24324: service handle not initialized
ORA-01041: internal error. hostdef extension doesn't exist
期初怀疑是存储的问题，于是开始检查存储状态，本套RAC使用multipath +asmlib的架构
查询multipath 状态，均为active
[root@rac2 bin]# multipath -ll
360a9800044336b327a24446172587864 dm-5 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:0 sdau 66:224 [active][ready]
\_ 3:0:1:0 sdq 65:0 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:0 sdaf 65:240 [active][ready]
\_ 3:0:0:0 sdb 8:16 [active][ready]
360a9800044336b327a24446172587862 dm-6 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:1 sdav 66:240 [active][ready]
\_ 3:0:1:1 sdr 65:16 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:1 sdag 66:0 [active][ready]
\_ 3:0:0:1 sdc 8:32 [active][ready]
360a9800044336b327a2444617258786e dm-13 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:8 sdbc 67:96 [active][ready]
\_ 3:0:1:8 sdy 65:128 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:8 sdan 66:112 [active][ready]
\_ 3:0:0:8 sdj 8:144 [active][ready]
360a9800044336b327a24446172587876 dm-11 NETAPP,LUN
[size=2.0G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:6 sdba 67:64 [active][ready]
\_ 3:0:1:6 sdw 65:96 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:6 sdal 66:80 [active][ready]
\_ 3:0:0:6 sdh 8:112 [active][ready]
[size=10G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:13 sdac 65:192 [active][ready]
\_ 4:0:1:13 sdbg 67:160 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:13 sdar 66:176 [active][ready]
\_ 3:0:0:13 sdn 8:208 [active][ready]
360a9800044336b327a24446172587868 dm-0 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:10 sdaa 65:160 [active][ready]
\_ 4:0:1:10 sdbe 67:128 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:10 sdap 66:144 [active][ready]
\_ 3:0:0:10 sdl 8:176 [active][ready]
360a9800044336b327a24446172587870 dm-9 NETAPP,LUN
[size=2.0G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:4 sday 67:32 [active][ready]
\_ 3:0:1:4 sdu 65:64 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:4 sdaj 66:48 [active][ready]
\_ 3:0:0:4 sdf 8:80 [active][ready]
360a9800044336b327a24446172587970 dm-1 NETAPP,LUN
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:15 sdae 65:224 [active][ready]
\_ 4:0:1:15 sdbi 67:192 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:15 sdat 66:208 [active][ready]
\_ 3:0:0:15 sdp 8:240 [active][ready]
360a9800044336b327a24446172587a55 dm-3 NETAPP,LUN
[size=5.0G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:14 sdad 65:208 [active][ready]
\_ 4:0:1:14 sdbh 67:176 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:14 sdas 66:192 [active][ready]
\_ 3:0:0:14 sdo 8:224 [active][ready]
360a9800044336b327a2444617258786a dm-8 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:3 sdax 67:16 [active][ready]
\_ 3:0:1:3 sdt 65:48 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:3 sdai 66:32 [active][ready]
\_ 3:0:0:3 sde 8:64 [active][ready]
360a9800044336b327a24446172587872 dm-14 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 4:0:1:9 sdbd 67:112 [active][ready]
\_ 3:0:1:9 sdz 65:144 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:9 sdao 66:128 [active][ready]
\_ 3:0:0:9 sdk 8:160 [active][ready]
360a9800044336b327a24446172587972 dm-2 NETAPP,LUN
[size=10G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:13 sdac 65:192 [active][ready]
\_ 4:0:1:13 sdbg 67:160 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:13 sdar 66:176 [active][ready]
\_ 3:0:0:13 sdn 8:208 [active][ready]
360a9800044336b327a24446172587868 dm-0 NETAPP,LUN
[size=200G][features=3 queue_if_no_path pg_init_retries 50][hwhandler=1 alua][rw]
\_ round-robin 0 [prio=50][active]
\_ 3:0:1:10 sdaa 65:160 [active][ready]
\_ 4:0:1:10 sdbe 67:128 [active][ready]
\_ round-robin 0 [prio=10][enabled]
\_ 4:0:0:10 sdap 66:144 [active][ready]
\_ 3:0:0:10 sdl 8:176 [active][ready]
查询asmlib中asm磁盘，也都可以正常识别，此时排除了存储的故障，开始定位grid的日志
[root@rac2 bin]# /etc/init.d/multipathd restart
Stopping multipathd daemon: [ OK ]
Starting multipathd daemon: [ OK ]
[root@rac2 bin]# /etc/init.d/oracleasm restart
Dropping Oracle ASMLib disks: [ OK ]
Shutting down the Oracle ASMLib driver: [ OK ]
Initializing the Oracle ASMLib driver: [ OK ]
Scanning the system for Oracle ASMLib disks: [ OK ]
[root@rac2 bin]# oracleasm scandisks
Reloading disk partitions: done
Cleaning any stale ASM disks...
Scanning system for ASM disks...
[root@rac2 bin]# oracleasm listdisks
ASMLB_OCR01
ASMLB_OCR02
ASMLB_OCR03
ASMLB_ORCL01
ASMLB_ORCL02
ASMLB_ORCL03
ASMLB_ORCLCTL
ASMLB_ORCLFRA
ASMLB_ORCLREDO
ASMLB_YYZF01
ASMLB_YYZF02
ASMLB_YYZF03
ASMLB_YYZFCTL
ASMLB_YYZFFRA
ASMLB_YYZREDO
