首页 > 数据库 > 数据库开发技术 > Kali Linux取证分析之Binwalk
Binwalk是用于搜索给定二进制镜像文件以获取嵌入的文件和代码的工具。可帮助产品安全研究人员提取固件映像的组件。由于Binwalk用于分析,逆向工程和提取固件映像,因此您可以使用此工具反转路由器的固件映像。通过这种方式,您可以了解它的工作原理,并识别嵌入在固件映像中的文件和代码
binwalk预装在Kali Linux操作系统。要安装 Binwalk 及其依赖的任何其他软件包,请使用以下命令:
apt-get install binwalk
Signature Scan Options:
-B, --signature Scan target file(s) for common file signatures
-R, --raw=<str> Scan target file(s) for the specified sequence of bytes
-A, --opcodes Scan target file(s) for common executable opcode signatures
-m, --magic=<file> Specify a custom magic file to use
-b, --dumb Disable smart signature keywords
-I, --invalid Show results marked as invalid
-x, --exclude=<str> Exclude results that match <str>
-y, --include=<str> Only show results that match <str>
Extraction Options:
-e, --extract Automatically extract known file types
-D, --dd=<type[:ext[:cmd]]> Extract <type> signatures (regular expression), give the files an extension of <ext>, and execute <cmd>
-M, --matryoshka Recursively scan extracted files
-d, --depth=<int> Limit matryoshka recursion depth (default: 8 levels deep)
-C, --directory=<str> Extract files/folders to a custom directory (default: current working directory)
-j, --size=<int> Limit the size of each extracted file
-n, --count=<int> Limit the number of extracted files
-0, --run-as=<str> Execute external extraction utilities with the specified user's privileges
-1, --preserve-symlinks Do not sanitize extracted symlinks that point outside the extraction directory (dangerous)
-r, --rm Delete carved files after extraction
-z, --carve Carve data from files, but don't execute extraction utilities
-V, --subdirs Extract into sub-directories named by the offset
Entropy Options:
-E, --entropy Calculate file entropy
-F, --fast Use faster, but less detailed, entropy analysis
-J, --save Save plot as a PNG
-Q, --nlegend Omit the legend from the entropy plot graph
-N, --nplot Do not generate an entropy plot graph
-H, --high=<float> Set the rising edge entropy trigger threshold (default: 0.95)
-L, --low=<float> Set the falling edge entropy trigger threshold (default: 0.85)
Binary Diffing Options:
-W, --hexdump Perform a hexdump / diff of a file or files
-G, --green Only show lines containing bytes that are the same among all files
-i, --red Only show lines containing bytes that are different among all files
-U, --blue Only show lines containing bytes that are different among some files
-u, --similar Only display lines that are the same between all files
-w, --terse Diff all files, but only display a hex dump of the first file
Raw Compression Options:
-X, --deflate Scan for raw deflate compression streams
-Z, --lzma Scan for raw LZMA compression streams
-P, --partial Perform a superficial, but faster, scan
-S, --stop Stop after the first result
General Options:
-l, --length=<int> Number of bytes to scan
-o, --offset=<int> Start scan at this file offset
-O, --base=<int> Add a base address to all printed offsets
-K, --block=<int> Set file block size
-g, --swap=<int> Reverse every n bytes before scanning
-f, --log=<file> Log results to file
-c, --csv Log results to file in CSV format
-t, --term Format output to fit the terminal window
-q, --quiet Suppress output to stdout
-v, --verbose Enable verbose output
-h, --help Show help output
-a, --finclude=<str> Only scan files whose names match this regex
-p, --fexclude=<str> Do not scan files whose names match this regex
-s, --status=<int> Enable the status server on the specified port
在给定的固件文件(dd-wrt.v24-13064_VINT_mini.bin)上运行文件签名扫描(-B):
binwalk -B dd-wrt.v24-13064_VINT_mini.bin
DECIMAL HEX DESCRIPTION
-------------------------------------------------------------------------------------------------------------------
0 0x0 TRX firmware header, little endian, header size: 28 bytes, image size: 2945024 bytes, CRC32: 0x4D27FDC4 flags: 0x0, version: 1
28 0x1C gzip compressed data, from Unix, NULL date: Wed Dec 31 19:00:00 1969, max compression
2472 0x9A8 LZMA compressed data, properties: 0x6E, dictionary size: 2097152 bytes, uncompressed size: 2084864 bytes
622592 0x98000 Squashfs filesystem, little endian, DD-WRT signature, version 3.0, size: 2320835 bytes, 547 inodes, blocksize: 131072 bytes, created: Mon Nov 2 07
